GEAR
SPECIFICATION |
DRIVEN
MOTOR |
75 Kw x
1750 RPM |
OUTPUT
SHAFT SPEED |
105 RPM
|
REDUCTION
RATIO |
1/9.9026 |
LUBRICANT |
ISO VG 220.50
LITER |
WEIGHT |
850 Kg |
NAME |
STEP |
1 STEP
GEAR |
2 STEP
GEAR |
PART |
PINION |
GEAR |
PINION |
GEAR |
MODULE |
3.5` |
5 |
NO
DF TEETH |
22 |
75 |
21 |
61 |
RATIO |
1/3.4 |
1/2.904 |
RPESSURE
ANGLE |
20 ° |
20 ° |
HELIX
ANGLE |
(R) 15
° (L) |
(R) 10
° (L) |
STANDARD
P.C.D |
79.716 |
271.760 |
106.620 |
309.705 |
WIDTH
OF TEETH |
70 |
65 |
92.5 |
90 |
HARDNESS
OF TEETH |
HRc60±2 |
HRc58±2 |
HRc60±2 |
HRc58±2 |
MATERIAL |
SNCM21 |
SNCM21 |
SNCM21 |
SNCM21 |
HEAT
TREATMENT |
CARBURIZING |
CARBURIZING |
GRADE |
JIS 2
|
JIS 2 |
|
|
| |
|
|
 |
|
