GEAR
SPECIFICATION |
DRIVEN
MOTOR |
22 Kw x 1750
RPM |
OUTPUT
SHAFT SPEED |
105 RPM |
REDUCTION
RATIO |
1/10.441 |
LUBRICANT |
ISO VG 220.20
LITER |
WEIGHT |
250 Kg |
NAME |
STEP |
1 STEP
GEAR |
2 STEP
GEAR |
PART |
PINION |
GEAR |
PINION |
GEAR |
MODULE |
2.5` |
3.5 |
NO
DF TEETH |
21 |
72 |
22 |
67 |
RATIO |
1/3.428 |
1/3.045 |
RPESSURE
ANGLE |
20 ° |
20 ° |
HELIX
ANGLE |
(R) 15
° (L) |
(R) 15
° (L) |
STANDARD
P.C.D |
54.352 |
186.350 |
70.716 |
242.772 |
WIDTH
OF TEETH |
50 |
45 |
65 |
60 |
HARDNESS
OF TEETH |
HRc60±2 |
HRc58±2 |
HRc60±2 |
HRc58±2 |
MATERIAL |
SCM415 |
SCM415 |
SCM415 |
SCM415 |
HEAT
TREATMENT |
CARBURIZING |
CARBURIZING |
GRADE |
JIS 2
|
JIS 2 |
|
|
| |
|
|
 |
|
