GEAR
SPECIFICATION |
DRIVEN
MOTOR |
260 Kw x 1750
RPM |
OUTPUT
SHAFT SPEED |
105 RPM |
REDUCTION
RATIO |
1/10.4318 |
LUBRICANT |
ISO VG 220.50
LITER |
WEIGHT |
3200 Kg |
NAME |
STEP |
1 STEP
GEAR |
2 STEP
GEAR |
PART |
PINION |
GEAR |
PINION |
GEAR |
MODULE |
7 |
10 |
NO
DF TEETH |
22 |
81 |
24 |
68 |
RATIO |
1/3.68 |
1/2.834 |
RPESSURE
ANGLE |
20 ° |
20 ° |
HELIX
ANGLE |
(R) 15
° (L) |
(L) 15
° (R) |
STANDARD
P.C.D |
159.43 |
587 |
248.466 |
703.998 |
WIDTH
OF TEETH |
170 |
160 |
190 |
180 |
HARDNESS
OF TEETH |
HRc60±2 |
HRc58±2 |
HRc60±2 |
HRc58±2 |
MATERIAL |
SNCM21 |
SNCM21 |
SNCM21 |
SNCM21 |
HEAT
TREATMENT |
CARBURIZING |
CARBURIZING |
GRADE |
JIS 2
|
JIS 2 |
|
|
| |
|
|
 |
|
