GEAR
SPECIFICATION |
DRIVEN
MOTOR |
110Kw * 1750
RPM |
OUTPUT
SHAFT SPEED |
110 RPM |
REDUCTION
RATIO |
1 / 10.605 |
LUBRICANT |
ISO VG 220 |
WEIGHT |
|
NAME |
STEP |
1 STEP
GEAR |
2 STEP
GEAR |
PART |
PINION |
GEAR |
PINION |
GEAR |
MODULE |
4.5` |
6.5 |
NO
DF TEETH |
19 |
65 |
20 |
62 |
RATIO |
1 / 3.421 |
1 / 3.1 |
RPESSURE
ANGLE |
20 ° |
20 ° |
HELIX
ANGLE |
(R) 15
° (L) |
(R) 12°
(L) |
STANDARD
P.C.D |
88.516 |
302.82 |
132.9 |
412 |
WIDTH
OF TEETH |
110 |
90 |
125 |
120 |
HARDNESS
OF TEETH |
HRc60±2 |
HRc58±2 |
HRc60±2 |
HRc58±2 |
MATERIAL |
SNCM21 |
HEAT
TREATMENT |
CARBURIZING |
GRADE |
JIS 2 |
|
|
| |
|
|
 |
|
